The ADS- 3530 is an ideal automatic dip soldering machine which is more efficient and reliable than hand soldering or manual dipping, it adopts a pin-type, fixture-less board holder for PCBs up to 350 x 300 mm .Dip soldering speed and angle is adjustable through controlling left and right elevator motor speed .
| The Auto-Dip 3530 includes the standard pin-type PCB holder that allows multi-board processing with easy loading/unloading. |
| Stainless steel solder pot;Titaniium solder pot is optional. |
| Pedestal is optional:L600*W750*H677 |
| Independent, dial-adjustable, speed controls for left and right elevator motors control dipping angle and speed to simulate wave soldering. Multi-day, 24-hr. timer for automatic startup;Digtal timer for setting solder dwell time;Digital PID solder pot temperature controller for lead-free SAC or SnPb solders. |
| PLC control , CE certificated wiring. |
Auto Dip Soldering Machine ADS-3530 Features
● Pin-type PCB holder for boards from 60 x 60 mm to 350 x 300 mm ; no special fixturing or pallets needed. pallets needed. |
● Multiple small boards placed on 350 x 300mm pin type holder can be processed simultaneously placement of PCBs and assemblies in loading area. |
● Independent, dial-adjustable, speed controls for left and right elevator motors control dipping angle and speed to simulate wave soldering. |
● Digital timer for setting solder dwell time; typically 3-5 seconds. |
● Stainless steel solder pot; holds approx. 70 Kg (154 lbs.) lead-free SAC; approx. 85 Kg (187 lbs.) SnPb,Titaniium solder pot is optional |
● Digital PID solder pot temperature controller for lead-free SAC or SnPb solders. |
● Automatic dross skimmer and collection trough; cycles prior to dip soldering function. |
● Multi-day, 24-hr. timer for automatic startup; allows melting of solder and heating to desired solder bath temperature prior to production. |
● Foot pedal for hands-free actuation of soldering cycle. |
● Optional spray fluxer accessory available. |
|
Auto Dip Soldering Machine ADS-3530 Include
1 PC. ADS-3530 Auto Dip Soldering Machine with:
◎ PCB holder for boards from 60x60mm to 350x300mm
◎ Dial adjustable dip speed/dip angle controls
◎ Digital timer for solder dwell time
◎ SUS solder pot ，approx. 70 Kg (154 lbs.) Lead-Free SAC
◎ Digital PID solder pot temperature controller
◎ Automatic dross skimmer and collection trough
◎ Multi-day, 24-hr. timer for automatic startup
◎ Foot pedal actuation
◎ 1-Year Warranty On All Parts
